Focusrite Saffire Pro 14
Product Details:
X
Product Description
Focusrite Saffire PRO 14
8-in/6-out 24-bit/96kHz FireWire Interface with 2 Mic Preamps, S/PDIF, MIDI I/O, DSP Mixer, and Plug-ins.
Incredible Flexibility, Pro Quality, Great Price!
When you want to get your mic or instrument signal to your DAW with the highest possible quality, then you need Focusrite. And now, Focusrite packs that unparalleled quality into a compact, feature-rich, desktop-friendly FireWire interface that's priced well within your reach. The Saffire PRO 14 gives you an 8-in/6-out box that's absolutely loaded with great stuff - starting with two award-winning Focusrite preamps. You also get an onboard low-latency 18 x 6 DSP mixer, an amazing suite of VST/AU processing plug-ins, Ableton Live Lite 8 software, and even a bundle of outstanding loops and synths. Ready to get great results? Then you're ready for the Saffire PRO 14!Focusrite designed the Saffire PRO 14 to put pro quality in your desktop or mobile rig, and that's exactly what it delivers. In addition to this 24-bit/96kHz interface's two premium Focusrite preamps and XLR combo inputs, the Saffire PRO 14 gives you a pair of hi-Z inputs; it's ready for both mics and instruments - no need for an additional DI! Use bus power and take the Saffire PRO 14 on the road, or choose the included power supply. You get an elegantly clean front-panel layout, with a pair of gain knobs, a monitor level knob, a dedicated headphone volume control, and a phantom power switch. The XLR combo jacks are also conveniently located on the front of the Saffire PRO 14. You also get S/PDIF and MIDI I/O!
The Saffire PRO 14 isn't just a premium FireWire interface. It's an in-the-box recording solution! The onboard Saffire MixControl DSP mixer/router gives you amazingly flexible routing capability, so you can take full advantage of the great sound you get from the interface. The DSP mixer works with exceptionally low latency, for accurate, comfortable monitoring. Focusrite bundled the Saffire PRO 14 with an astounding collection of processing plug-ins, virtual synths, loops, and even Ableton Live Lite 8 production software. This package adds even more value to the already astonishing deal you get on the interface.
Focusrite Saffire PRO 14 FireWire 8 x 6 Interface Features:
Microphone Inputs (1-2)
- Frequency Response: 20Hz-20kHz +/- 0.2 dB
- Gain Range: +13dB to +60dB
- Maximum Headroom +8dBu
- THD+N: 0.001% (measured at 1kHz with a 20Hz/22kHz bandpass filter)
- Noise EIN: 124dB analogue to digital (measured at 60dB of gain with 150-ohm termination - 20Hz/22kHz bandpass filter)
- Input Impedance: 2k ohm
Line Inputs (1-2)
- Frequency Response: 20Hz-20kHz +/- 0.2dB
- Gain Range: -10dB to +36dB
- THD+N: 0.001% (measured with 0dBFS input and 22Hz/22kHz bandpass filter)
- Noise: -90dBu (22Hz/22kHz bandpass filter)
- Input Impedance: >10k ohm
Line Inputs (3-4)
- Frequency Response: 20Hz-20kHz +/- 0.2 dB
- Gain Range: Switchable between +16dBu or -10dBV for 0dBFS (balanced inputs) THD+N: 0.003% (measured at 1kHz with a 20Hz/22kHz bandpass filter)
- Noise: -100dBu (22Hz/22kHz bandpass filter)
- Input Impedance: >10k ohm
Instrument Inputs (1 and 2)
- Frequency Response: 20Hz-20kHz +/- 0.1dB
- Gain Range: +13dB to +60dB
- THD+N: 0.004% (measured with 0dBu input and 20Hz/22kHz bandpass filter)
- Noise: -87dBu (20Hz/22kHz bandpass filter)
- A/D Dynamic Range > 109dB (A-weighted), all analogue inputs
- D/A Dynamic Range > 106dB (A-weighted), all analogue outputs
- Clock Sources: Internal Clock, Sync to Word Clock on SPDIF Input (RCA)
- JetPLLTM PLL technology for jitter reduction
- Clock jitter < 250 picoseconds
- Supported Sample Rates: 44.1kHz, 48kHz, 88.2kHz, 96kHz
- 8 input channels to computer: Analog (4), SPDIF (2) and Loop-back (2)
- 6 physical output channels from computer: Analog (4), SPDIF (2)
- 12 DAW output streams
- Assignable 18-input x 6-output mixer
- Analogue Channel Inputs (Inputs 1-2)
- 2 Mic XLR Combo (channels 1-2) on front panel
- 2 Line 1/4" TRS (channels 3-4) on rear panel
- Automatic switching between Mic / Line (channels 1-2)
- Switching between Line/Instrument Inputs (channels 1-2) via Saffire MixControl Application
- Switching between +16dBu (low) and -10dBV (high) gain on inputs 3-4 via Saffire MixControl Application
- Stereo S/PDIF input on RCA
- 4 x 1/4" TRS Output Jacks
- Output Level control (analogue) for outputs 1 and 2
- Stereo Headphones Mix 1 on 1/4" TRS (also routed to Outputs 3 and 4) with independent volume control
- Stereo S/PDIF Output on RCA
- 1 x 6-pin FireWire S400 socket
- 2 Standard 5-pin DIN MIDI connectors: In and Out
- DC Power Input Connector (for use with supplied universal input power supply)
- 2 x 2 segment input meters, Sig (-18) and O/L (0dBFS)
- "LKD" Locked Indicator
- "FW" Host Connected Indicator
- "Power" Indicator
- Instrument input source selection LED for channels 1 and 2
- Phantom Power (48V) switch and LED for inputs 1 and 2
- Dimensions: 8-1/2 W" x 1-4/5" H x 8-7/10" D
